Standard Methods for the Examination of Water and Wastewater
© Copyright 1999 by American Public Health Association, American Water Works Association, Water Environment Federation
Part 4000 INORGANIC NONMETALLIC CONSTITUENTS
4010 INTRODUCTION
The analytical methods included in this part make use of classical wet chemical techniques
and their automated variations and such modern instrumental techniques as ion chromatography.
Methods that measure various forms of chlorine, nitrogen, and phosphorus are presented. The
procedures are intended for use in the assessment and control of receiving water quality, the
treatment and supply of potable water, and the measurement of operation and process efficiency
in wastewater treatment. The methods also are appropriate and applicable in evaluation of
environmental water-quality concerns. The introduction to each procedure contains reference to
special field sampling conditions, appropriate sample containers, proper procedures for sampling
and storage, and the applicability of the method.
4020 QUALITY ASSURANCE/QUALITY CONTROL
4020 A. Introduction
Without quality control results there is no confidence in analytical results reported from
tests. As described in Part 1000 and Section 3020, essential quality control measurements
include: method calibration, standardization of reagents, assessment of individual capability to
perform the analysis, performance of blind check samples, determination of the sensitivity of the
test procedure (method detection level), and daily evaluation of bias, precision, and the presence
of laboratory contamination or other analytical interference. Details of these procedures,
expected ranges of results, and frequency of performance should be formalized in a written
Quality Assurance Manual and Standard Operating Procedures.
For a number of the procedures contained in Part 4000, the traditional determination of bias
using a known addition to either a sample or a blank, is not possible. Examples of these
procedures include pH, dissolved oxygen, residual chlorine, and carbon dioxide. The inability to
perform a reliable known addition does not relieve the analyst of the responsibility for evaluating
test bias. Analysts are encouraged to purchase certified ready-made solutions of known levels of
these constituents as a means of measuring bias. In any situation, evaluate precision through
analysis of sample duplicates.
Participate in a regular program (at a minimum, annually, and preferably semi-annually) of
proficiency testing (PT)/performance evaluation (PE) studies. The information and analytical
confidence gained in the routine performance of the studies more than offset any costs associated
